Bariatric

FEATURES
  • BS 2838-2: 1991 Examination & general treatment couches, build, performance & safety specifications
  • EN 60601-1:2006+A12:2014 Medical electrical equipment. General requirements for basic safety & essential performance
  • Electric height adjustment from 500 - 1050mm
  • Electric backrest, adjustable from 0 to +80°
  • Electric foot section/s, adjustable from 0 to -85°
  • Retractable castors fitted to both ends to assist with movement & positioning
  • One adjustable foot fitted to allow levelling on uneven floors
  • Clearance beneath frame allows access for mobile hoists
  • Fitted with a UK 3 pin plug (230V ~, 50/60Hz) & supplied with a handset with a digital display, providing live feedback of
    height, section & Trendelenburg tilt angle (°).
  • Seamless upholstery using flame retardant anti-microbial vinyl
  • Frames prepared to accept optional accessories
  • Maximum capacity 325kg

OVERALL DIMENSIONS (w x d x h)
  • 850 x 1800 x 500 - 1050mm

STANDARD COLOURS
  • Paint - White
  • Vinyl - Blue

View the full range:

Examination / Treatment Couches & Chairs Bariatric Couches
Download Product PDF
Need Advice? Contact Us
Code Description Overall Dimensions (W x D x H) Enquiry
5EC/SM3583-TMO-3WH Electric Height, Backrest & Foot Section 850 x 1800 x 500 - 1050mm minus plus
5EC/SM3584-TMO-4WH Electric Height, Backrest & Foot Sections, Dual Foot 850 x 1800 x 500 - 1050mm minus plus
